Wheel Cylinders and Fittings (Brakes)

Author: hemi354az (Show all albums) Pictures showing the thin copper washer required AT the wheel cylinder where the flex brake hose attaches, the bleeder screw and what the hole in the wheel cylinders look like at the bottom.

Show Newest Photos First | Show Oldest Photos First 7 Photos - Page : [1]
(1 Comments) FMC #120 Front Brake hose.	FMC #120 REAR Brake hose- Note thin washer between the 7/16-20 crimp type hose fitting and the wheel cylinder.	WC28851 Wheel Cylinder with supplied 7/16-20 Bleed Screw.	WC28851 with Bleed Screw installed. Note supplied thin washer for "other" 7/16-20 hose fitting hole.
WC28851 "INSIDE" transfer fitting hole (3/8-24) with supplied thin washer for that fitting.	FMC #120 FRONT Brake hose- Note thin washer between the 7/16-20 crimp type hose fitting and the wheel cylinder.	FMC #120 FRONT brake Hose at frame clip attachment. The 7/16-24 female inverted flare fitting is the crimp type to mate with the 1/4" steel tube nut.
